Hayner PCB is a PCB manufacturer in China. We are well-known in the electronic industry as multilayer PCB manufacturers. We make rigid, rigid-flex, and flex multilayered PCBs, as well as HDI multilayered boards as well. One of the key advantages of these multilayer PCBs is their high density integration, which allows for more complex and efficient circuit designs.
The electronic industry uses several types of PCBs with many layers. These include:single-Layer PCBs,double-Layer PCBs andmultilayer PCBs.
Multilayer PCB is a printed circuit board with at least three conductive layers. The electrical connection between multilayer printed circuit board layers is realized through plated through holes on the circuit board. The number of layers of Multilayer circuit board can be 4, 6, 8, 10 Up to 100 layers.
As a multi-layer PCB manufacturer, Hayner PCB makes high quality PCBs for our customers. The advantage of using a multi-layer board is the designer can use multiple layers for all the traces they require to connect their components on the board. This helps to realize a complicated circuit for a small product such as a mobile phone or a pocket recorder.
Most manufacturers of electronic products use multi-layer PCBs as they offer high design flexibility, stability, and reliable device performance.
Multilayer PCBs have some good characters , including smaller size, light weight, high durability, increased flexibility,and higher assembly density and so on.
Multilayer PCBs have become an integral part of electronic products and are widely used in many industries, like computer, medical equipment, aerospace, telecommunication, electronics etc.
|
Specifications |
Capability |
|
HDI PCB Material |
FR-4, HI Tg, Rogers, Taconic, Argon etc. |
|
HDI PCB layer |
1-30 layer |
|
HDI PCB types |
single/double-sided, multi-layer |
|
Copper Thickness |
1-6oz |
|
Board Thickness |
S/D 0.2-0.7mm, Multi-layer:0.40-7.0mm |
|
Surface finish |
HASL, OSP, Immersion gold, Flash Gold Finger |
|
Min. Hole Size |
0.2mm mechanical drill |
|
4mil laser drill |
|
|
Min.Line Spacing / Min.Line Width |
6mil |
|
6mil |
|
|
Min. Solder Mask Bridge |
0.08mm |
|
Max. Production Size |
400x510mm |
|
Impedance control |
50Ω ±5Ω, 90Ω ±9Ω, 100Ω ±10Ω |
|
Aspect ratio |
15:1 |
|
Via Plugging Capability |
0.2-0.8mm |
|
PCB Standard |
IPC-II Standard |
|
Warp & Twist |
0.75% |
|
Certificate |
ISO9001. IATF16949. RoSH.UL. |
|
Quality Control |
X-ray, AOI Test, Function Test (100% Test) |
|
Delivery |
PCB 3-7 Days, PCBA 2-3 weeks |
Seven SMT production lines --10million points/day
Four THT production lines --- 0.50million points /day
Three Final assembly lines ----15,000pcs/day
One Aging room -------------- 2,000PCS/day
Three Spraying lines
