The High Frequency PCB is engineered to minimize signal reflection, crosstalk, and electromagnetic interference (EMI), ensuring clean and reliable signal transmission. Its superior quality and performance make it the ideal choice for designers and engineers seeking to push the boundaries of high-speed electronics. Whether you're developing next-generation communication systems, high-performance computing platforms, or advanced radar systems, Hayner PCB 's main product - High Frequency PCB is the perfect foundation for your innovative designs.
As a trusted manufacturer and supplier, Hayner PCB ensures that every High Frequency PCB undergoes rigorous quality control procedures, ensuring that the highest standards are met. Using premium materials and state-of-the-art manufacturing techniques, Hayner PCB produces PCBs with precise trace widths, tight tolerances, and optimized dielectric constants, allowing for seamless transmission of high-frequency signals.
High frequency PCB is a printed circuit board specifically designed for processing high-frequency signals. Its design, manufacturing, and material selection are all optimized for the transmission characteristics of high-frequency signals to ensure the stability, integrity, and low loss of the signal during transmission.
High frequency PCB is commonly used in wireless communication, microwave communication, satellite communication, radar systems and other fields, which require extremely high signal transmission speed and stability. Therefore, the performance of high-frequency PCB directly affects the performance of the entire system.
High frequency processing capability: High frequency PCB can process high-frequency signals up to GHz level, meeting the needs of high-speed data transmission and complex signal processing.
Low loss: High frequency PCB adopts low loss materials and structural design to reduce energy loss during signal transmission and improve signal transmission efficiency.
Good electromagnetic compatibility: High frequency PCB reduces electromagnetic interference and crosstalk through reasonable layout and grounding design, ensuring stable signal transmission.
High precision manufacturing: The manufacturing process of high-frequency PCB requires high-precision equipment and processes to ensure the accuracy and consistency of the circuit.
With the development of technologies such as wireless communication and the Internet of Things, the demand for high-frequency PCBs is constantly increasing. High frequency PCB board is a special type of circuit board widely used in communication, medical, industrial control, automotive electronics, instrumentation, aerospace, computers and servers, Internet of Things and other fields, providing reliable signal transmission and precise control. It is an important electronic component.
|
Specifications |
Capability |
|
HDI PCB Material |
FR-4, HI Tg, Rogers, Taconic, Argon etc. |
|
HDI PCB layer |
1-30 layer |
|
HDI PCB types |
single/double-sided, multi-layer |
|
Copper Thickness |
1-6oz |
|
Board Thickness |
S/D 0.2-0.7mm, Multi-layer:0.40-7.0mm |
|
Surface finish |
HASL,OSP,Immersion gold,Flash Gold Finger |
|
Min. Hole Size |
0.2mm mechanical drill |
|
4mil laser drill |
|
|
Min.Line Spacing / Min.Line Width |
6mil |
|
6mil |
|
|
Min. Solder Mask Bridge |
0.08mm |
|
Max. Production Size |
400x510mm |
|
Impedance control |
50Ω ±5Ω, 90Ω ±9Ω, 100Ω ±10Ω |
|
Aspect ratio |
15:1 |
|
Via Plugging Capability |
0.2-0.8mm |
|
PCB Standard |
IPC-II Standard |
|
Warp & Twist |
0.75% |
|
Certificate |
ISO9001. IATF16949. RoSH.UL. |
|
Quality Control |
X-ray, AOI Test, Function Test (100% Test) |
|
Delivery |
PCB 3-7 Days, PCBA 2-3 weeks |
Seven SMT production lines --10million points/day
Four THT production lines --- 0.50million points /day
Three Final assembly lines ----15,000pcs/day
One Aging room -------------- 2,000PCS/day
Three Spraying lines
