Known for its unparalleled quality and durability, Hayner's Ceramic PCB offers exceptional thermal conductivity, mechanical strength, and chemical resistance, making it ideal for high-temperature and harsh environment applications. As a manufacturer with a strong focus on quality, Hayner employs state-of-the-art technology and rigorous quality control measures to ensure that every Ceramic PCB meets the highest standards of performance and reliability. With a vast experience in the industry, Hayner stands as a reliable supplier, offering customized solutions and timely delivery to meet the unique needs of its customers. When it comes to Ceramic PCBs, Hayner PCB is the trusted choice for businesses seeking top-quality products from China.
Hayner PCB -Professional high-quality and faster Ceramic PCB manufacturer
Ceramic PCBs from Hayner PCB, a product proudly manufactured in China by a leading manufacturer and supplier in the electronics industry. This PCB meets the highest standards in the market, ensuring reliable and efficient power distribution.
"High quality, accurate delivery time, and low price" , it’s our guarantee to customers.
Ceramic PCB is a printed circuit board based on ceramics, which is a high thermal conductivity material that can quickly transfer heat from a hot spot and dissipate it.
The thermal conductivity of ceramic PCB is 9-20W/m.
Ceramic PCB has higher thermal conductivity than FR4, and the volume expansion coefficient is closer to the value of ordinary PCB conductor materials. This isreason that ceramics are often suitable for application in high-temperature environments or environments with repeated temperature cycles. Once the substrate temperature exceeds the glass transition temperature, the circuit board will begin to expand at a faster rate. Some Rogers materials have a high glass transition temperature and can provide stable volume expansion over a wide temperature range.
Ceramic circuit board is a type of printed circuit board that uses ceramic materials as a substrate. It has high thermal conductivity, high insulation, and high corrosion resistance, and is widely used in fields such as aerospace, automotive electronics, and medical equipment.
For example : High power LED lighting, automotive headlights and other high-power LED fields, semiconductor lasers, power electronic power devices, microwaves, optical communication, VCSEL, RF devices.
|
Specifications |
Capability |
|
PCB Material |
FR-4, HI Tg, Rogers, Taconic, Argon etc. |
|
PCB layer |
1-30 layer |
|
PCB types |
single/double-sided, multi-layer |
|
Copper Thickness |
1-6oz |
|
Board Thickness |
S/D 0.2-0.7mm, Multi-layer:0.40-7.0mm |
|
Surface finish |
HASL,OSP,Immersion gold,Flash Gold Finger |
|
Solder film |
green,red, yellow,blue,white,black,purple,matte black, matte green |
|
Screen printing |
white, black |
|
Min. Hole Size |
0.2mm mechanical drill |
|
4mil laser drill |
|
|
Min.Line Spacing / Min.Line Width |
6mil |
|
6mil |
|
|
Min. Solder Mask Bridge |
0.08mm |
|
Max. Production Size |
400x510mm |
|
Impedance control |
50Ω ±5Ω, 90Ω ±9Ω, 100Ω ±10Ω |
|
Aspect ratio |
15:1 |
|
Via Plugging Capability |
0.2-0.8mm |
|
PCB Standard |
IPC-II Standard |
|
Warp & Twist |
0.75% |
|
Certificate |
ISO9001.IATF16949.RoSH.UL. |
|
Quality Control |
X-ray, AOI Test, Function Test (100% Test) |
|
Delivery |
PCB 3-7 Days, PCBA 2-3 weeks |
Seven SMT production lines --10million points/day
Four THT production lines --- 0.50million points /day
Three Final assembly lines ----15,000pcs/day
One Aging room -------------- 2,000PCS/day
Three Spraying lines
