HIGHTechnology FR-4 PCB FABRICATION SERVICES

Hayner PCB, as a leading manufacturer, employs advanced production technologies and rigorous quality control measures to ensure that every FR-4 PCB is crafted to the highest standards of precision, reliability, and durability.

Hayner PCB FR-4 PCB productions is committed to providing high quality printed circuit board.We have earned the trust of thousands customers,and would be your best source to supply worry-freeFR-4 PCB manufacturer.

We are experienced in the manufacture of conventional FR-4 PCBs formore than 15years. FR-4 PCB is one of the most widely used types of PCBs in industrial electronics field. FR-4 PCB is very suitable for various general-purpose electronic devices, such as consumer electronics, computers,LED lighting,mobil phone etc.

With years of industry fabrication experience, we are proud to offer high quality, on-time delivery, and competitive pricing FR-4 PCB products whenever you need.

Contact Hayner PCB to learn more about our high-quality PCB fabrication services and how we can help with your next PCB projects.

Why more PCB FR-4 material is popular in PCB processing ?

FR-4 material is a low-cost material.

FR-4 material has high dielectric strength, which contributes to its electrical insulation properties.

FR-4 material has a high strength-to-weight ratio and is light in weight.

FR-4 materials moisture-proof and also has a relative temperature.

FR-4 material has good electrical loss properties.

FR-4 PCB does not absorb water, so it is also suitable for various marine PCB applications.

All these features make it suitable for a wide range of environments and applications.

What functions to consider when selecting an FR-4 PCB ?

What Features to Look at When Choosing or Ordering an FR-4 Printed Circuit Board? Electrical engineers or technicians must look at the following features when choosing or ordering an FR-4 printed circuit board:

Thickness

The thickness of the FR4 paper will vary depending on your project. Ideally, you’ll need FR-4 with a thickness of 1.0 to 3.0 mm.

Impedance Matching

Impedance management in PCB design essentially means matching the qualities of the substrate material with the dimensions and placements of the traces to make sure the impedance of the trace’s signal is within a defined range of a given value.

Space & Flexibility

Depending on your project, you can choose FR4 material for your PCB board. Generally, people prefer thinner sheets as they take up less space and are more flexible.

Weight of the FR-4

Since the thickness dictates its weight, select lighter weight FR4 boards for ignition products.

Thermal Conductivity

To determine temperature management of the FR4, look at the thermal coefficient value of its dielectric constant. However, the fact that it is heat resistant is one of the reasons why it is so widely used.

FR-4 PCB Capability
